Features

The Urban Wheelz Cargo was born out of experience and innovation. This Cargo bike had to be better than the rest. Safer, easier to build & maintain, efficient to transport & store, stronger, better brakes & safety belts, more stable and of course easier to ride than the existing cargo bikes in the market.

The motor and cargo

When it comes to the motor and cargo space, the Urban Wheelz Cargo is one of the best available cargo bicycles. The Urban Wheelz Cargo is powered by a strong 36V, 250W Bafang middle motor to ensure a smooth but speedy ride. In addition, the engine provides up to 80Nm of torque to provide the right amount of acceleration when you need it the most. The cargo space of the Urban Wheelz Cargo is designed to be able to transport up to four children. This also means that there is plenty of space to transport groceries or other goods without a problem.

Integrated Motor
Safe and Well Designed Interior

Safe interior

Whenever you want to take your children for a trip, safety of course is one of the biggest concerns. Therefore, we focused on making the cargo box as safe as possible. Cargo bikes tend to have cheap and low quality safety belts. We have invested in high quality and durable belts in order to make sure that your children are securely fastened when you take them for a ride! Additionally, we made sure that the inside of the cargo space has no screws or electronics sticking out, enhancing the safety and aesthetics of the bike.

Brakes & parking

Braking capabilities are one of the, if not the most important features of any electric bike. Most of the cargo bikes on the market have mechanical brakes with a steel brake cable. This functions well on a regular bicycle but is not efficient enough for a cargo bike, especially if the cargo box is loaded. When using a 3-wheel cargo bike it is extremely important that both front wheels have exactly the same brake pressure, otherwise the cargo bike will tilt left or right severely when using the brakes, this is extremely dangerous. The Urban Wheelz Cargo is equipped with Tektro hydraulic disc brakes including double parking brake. This means that the bike will stop within 5 meters with a total weight of 225kg! Further information regarding the braking can be found below, in the ISO 4210 test results.

Well Constructed and Safe Bike with Great Braking
ISO Approved Braking System

ISO approved

The Urban Wheelz Cargo bike has been tested by Extra Energy in Tanna Germany together with 13 other cargo bike brands, the results will be announced at Eurobike 2016 and also published here. Also the bike has been tested by Velotech.de for safety classification. As you can see in the downloads below, the Urban Wheelz Cargo has passed the ISO 4210 requirements regarding brake tests. Even at a total weight of 285 kg the bike stopped in 6,5 meters. Furthermore, the bike stays in a straight line, which is important to know that the bike will behave safely in the case of an emergency stop.

Compact design & efficient storage

We know that cargo bikes can be very clunky and hard to store. They are mostly stored outside, because they do not fit through any door. Therefore, we came up with our unique storage method for the Urban Wheelz Cargo! First of all the bike is only 76 cm wide, so it fits trough any normal door, than you can easily pick up the back of the bike and tilt it forward, so the nose of the cargo touches the ground. This way you can make the bike take up space vertically instead of horizontally, leaving up a lot free space in garages and storage environments. In total when stored, the bike only takes up 1 m3 of space at a height of 2.06 meters. The bike also comes in a neat transportation box. This box is the biggest colouring picture your children will ever see! A clever and fun way of using packing material!

Compact Design and Efficient Storage

Specifications

Specification Description
Battery A BMZ 36V 15.5Ah battery made in Germany. Including Rosenberger plug (Magnetic)
Frame Aluminium rear frame and a steel frame in the front
Cargo box High quality 12-layer concrete plywood
Motor Bafang Max Drive 36V 250W 80Nm middle engine
Transmission NuVinci 330 Harmony automatic gear system
Tires Schwalbe Big Apple Race Guard Tires and Schwalbe inner tire
Rims Mach1 25C Kargo rims and 13G stainless steel spokes
Saddle Selle Royal Giara Saddle
Handles Fizik grip tape
Lighting Spanninga Roxeo XEA front light, Lineo XD rear light
Lock Abus 5650 frame lock
Brakes Tektro hydraulic disc brakes (including double parking brakes)
Chain Guard Hebie Chainglider

Dealer

Dealer Pricing & quotation

Selling the Urban Wheelz Cargo bike in your shop is what we want! That is why we support dealerships to the maximum! Click below to request a quotation for your dealership.

Our dealer first policy

Our dealers are very important to us. To express this, we offer dealers our dealer first policy. This means, if a customer orders an Urban Wheelz Cargo directly via us and happens to live near a dealership that sells this bike, the customer then gets redirected to this dealership to do business with our dealers. This way we intend to help dealers by having them receive orders through our website. This way the Customer also gets to experience the bike first hand. In short: it is a win-win for all!

Dealer benefits & manuals

At Urban Wheelz Cargo dealers receive a bunch of benefits, if they do business with us. First of all, like mentioned in our dealer first policy, dealers receive extra customers through our website. This however is not the only benefit they receive. We even supply the bike 100% assembled and user ready to your shop or even better, directly to your customer! Transport costs are very low compared to any other cargo bike brands because we supply on an EU pallet. You can order from stock and get supplied within a few days!

We have also compiled a list of dealer specific manuals that can be downloaded below for more information:

Engine manual

Business opportunities

Urban Wheelz Cargo is aiming to grow through different dealerships. Therefore we offer B2B business opportunities for bicyle dealers all over Europe. For example, our company is already working with PostNL. We optimized the cargo box in order to fit paper mail and actually have it there in an organized way. Hence the previous, some of the mail in The Netherlands is already being delivered with cargo bicycles that are built by us! This is just one of the examples from us. We are motivated to expand through you!

Pricing

Urban Wheelz Cargo

Request pricing information

  • 24 months warranty on complete bike
  • Rain cover
  • 2 soft seats
  • Abus frame lock
  • 100% assembled, ride ready!

Affordability

At Urban Wheelz Cargo we believe that the price of a product should represent the quality and features that you receive. To accomplish this, we have decided to minimize marketing efforts in order to reduce costs. We also decided to use innovative solutions to make the product more valuable to our customers. We have managed to accomplish this increase in value for our customers in the areas of: storage space needed to store our product, safety, efficiency, and many more! All of this makes it possible to sell our product at a very competitive price. This money will buy you a high end luxurious, high quality Cargo Bike. That’s a deal you cannot refuse!

Urban Wheelz Cargo Employee

Our beliefs

What we’re all about

The idea for the Urban Wheelz Cargo originated from the belief that current cargo bikes are not as functional, comfortable and efficient as they should be. This led the team to develop a new bike. We put so much time and effort into our product, that we feel it is superior to the competition. Hence the previous, we think marketing will not be necessary to sell our product. We focus on the quality of the product and not on the quantity we produce. This is why we do not want to sell as fast as possible, but to sell as much as we can produce with care. This also helped us greatly reducethe sales price to be competitive even with the use of our expensive, high quality parts. In short: We believe that it is possible to be innovative and push the envelope on what is possible while staying competitive, is that not a philosophy to believe in?

Innovation

The idea for the Urban Wheelz Cargo originated from the belief that current cargo bikes have a lot of issues that could be solved through innovation. With the help of a student from the TU Delft, we managed to overcome all of these issues, making the bike safer and more efficient. We are constantly improving our production methods and tweaking the bike to ensure the most pleasurable experience for you as a user!

Bike Handlebars

Local production

At Urban Wheelz Cargo we stand by our principals. One of the principals in which we believe, is that quality bikes should be manufactured locally. That way it is possible to keep all processes in check and running optimally. We also think that too many jobs are being shipped to countries overseas. Therefore, we want to support our own community by providing locals with work instead of giving the jobs away to foreign countries.

Production of Bicycle Wheels

High quality parts

Here at Urban Wheelz Cargo we believe that a product should have the highest possible quality. To accomplish this, we have decided to incorporate the best parts that we could find, in Urban Wheelz Cargo bicycles to ensure long durability, maximum comfort and optimal functionality. We also decided to use innovative solutions in combination with these high quality parts to make the product as valuable as possible for you as our customer!

Whole Urban Wheelz Cargo Bicycle

Customer

Warranty

We offer you 2 years of warranty on the Urban Wheelz Cargo, including the electronic parts. However, do not forget that a bicycle needs periodic maintenance. It is the owner’s responsibility that the bike gets regular and proper maintenance. This requirement has to be met in order to be eligible for a 2-year warranty. Periodic maintenance can only be done by a professional bicycle mechanic and maintenance invoices must be shown as proof of service.

Customer manuals

At Urban Wheelz Cargo we want to make sure our customers can find the right information when they need it. That is why we incorporated the bike manuals below.

Click the links below to download the manuals:

Battery Safety instructions
Charger manual
Max Drive
Technical owner manual
